Ventilation System Fan Filter In Air Filter NTL- FF255 Air flow 536m*3/ h fan cabinet

FOB Reference Price:Get Latest Price
US $5-12 / Pieces | 2 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Efficiency:
99.9%
Construction:
Box Filter
Filtration Grade:
Medium Filter
Medium Material:
Fiberglass
Porosity:
0.3u
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Natural
Model Number:
NTL-FF255
Dimension(L*W*H):
Standard Size
Weight:
0.5-1KG
Certification:
CE,RoHS
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Connection:
2 stranded wires, 300mm
Filter mat:
G4 acc. to DIN EN 779, filtering degree 94%
Supply Ability
Supply Ability:
30000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton
Port
ningbo/shanghai
Lead Time :
3 days
Product Description

 Fan Filter  NTL-FF204 | up to 24m³/h



• New air-flap outlet technology for high airflow

• Easy mounting

• Protection type test/Environmental rating by independent testing institutes

• Standard enclosure cut-out sizes (5 sizes)

• One filter mat

Fan filters are used to provide an optimum climate in enclosures and cabinets with electrical/electronic components. The interior temperature of an enclosure can be reduced by channelling cooler filtered outside air into the enclosure thus expelling heated internal air. The resulting airflow prevents formation of localised hot pockets in installations and protects electronic components from overheating.

The Fan filter series uses a new air-flap outlet technology for the air outlet and thus reaches a high degree of airflow. A ratchet mechanism is used for mounting and provides high stability and tightness. The system is a standard installation with a filter fan in the lower part of the enclosure which ensures that fresh air is fed into the enclosure (airflow direction "In"). This system consists of a filter fan and exit filter.
